Description
If you are unsure whether you require master or slave level Magic Motorsport Flex protocols, or if you need any help configuring your protocols, the technical support team is on hand to help and advise.
Therefore, if you have not already purchased your Magic Motorsport Flex hardware unit, you can see this here: https://viezu.com/shop/magic-motorsport-flex-tuning-tool-hardware/.
A full breakdown of Master protocols:
| SKU | Name | Description |
|---|---|---|
| FLS0.1M | SW Flex ECU (cars, vans, bikes) OBD/Bench Master | Flex OBD Bench ECU is the software package for the Flex programmer which allows you to work on engine ECUs in OBD and Bench mode. |
| FLS0.2M | W Flex TCU OBD/Bench/Boot(cars, bikes, vans) Mast | With this FLEX SW package, the user may work on all supported protocols for TCUs in OBD, Boot and Bench mode. In Bench mode, as in the case of ECUs, FLEX is able to give a complete reading and writing of the content. |
| FLS0.3M | SW Flex BDM Motorola MPC5xxx Master | This software package allows the user to work on BDM protocols from the Motorola MPC5xx family of microprocessors. It is recommended tha this SW package be used with FLEX and the complete FLEXible Bench kit to obtain more efficient results and safer working conditions with no connection errors. |
| FLS0.4M | SW Flex Boot Nexus MPC5xxx Master | This software package allows the user to work on all supported protocols from the Nexus MPC5xxx family of processors for ECUs and TCUs in bootloader mode. |
| FLS0.5M | SW Flex Full Master | This software package allows the user to work on the entire list of over 25,000 vehicles supported by Flex. Main features: all supported solutions for ECUs and TCUs coverage of all the available programming modes |
| FLS0.6M | SW Flex OBD/Bench/Boot Renesas SH7xxxx Master | This software package contains all the protocols for work in OBD, Boot and Bench on ECUs and TCUs that mount Renesas SH7xxxx microprocessors. This SW package also includes protocols for work on Kubota tractors via OBD, Boot and Bench and is is recommended to use these protocols with the FLX2.13 connection cable. |
| FLS0.7M | SW Flex Boot Infineon C165/166/167 Master | This FLEX SW package allows work in Bootloader mode on all control units that mount C165/166/167 Siemens microprocessors. This family o microprocessors is generally supported by older generation ECUs like ME7 and EDC15. |
| FLS0.8M | SW Flex Boot ST10 Master | This FLEX SW package allows work in Bootloader on control units that mount ST10F2xx microprocessors. This family of microprocessors is generally supported by Marelli in older generation models, such as IAW and is often equipped with an internal Flash. |
| FLS0.9M | SW Flex JTAG NEC76F00xx Master | This software package includes protocols for work in JTAG AUD on engine control units that mount NEC76F00xx microprocessors. This family of microprocessors can be found in Toyota Denso 275xxx or 175xxx engine control units. This SW package makes it possible to communicate with the supported units through the JTAG port so in this case, it is necessary to open the control unit. |
| FLS0.10M | Flex BenchBoot InfineonTC17xx/TC2xx/TC3xx Master | Complete Bench MEDC17 software package for programming BOSCH MEDC17 ECUs directly from the engine control unit connector. |
| FLS0.11M | Datalogger Plus Master | The best ally for each professional tuner, to always have every single parameter of the vehicle under control during modifying operations. |
| FLS0.13M | SW Flex Bikes OBD/Bench/Boot Master | FLEX SW package dedicated entirely to control units for motorcycles |
| FLS0.15M | SW Flex Heavy Duties OBD/Bench/Boot – Master | FLEX SW package designed to work on all categories of heavy-duty vehicles. |
A full breakdown of Slave Protocols:
| SKU | Name | Description |
|---|---|---|
| FLS0.1S | SW Flex ECU (cars, vans, bikes) OBD/Bench Slave | Flex OBD Bench ECU is the software package for the Flex programmer which allows you to work on engine ECUs in OBD and Bench mode. |
| FLS0.2S | W Flex TCU OBD/Bench/Boot (cars, bikes, vans) Slave | With this FLEX SW package, the user may work on all supported protocols for TCUs in OBD, Boot and Bench mode. In Bench mode, as in the case of ECUs, FLEX is able to give a complete reading and writing of the content. |
| FLS0.3S | SW Flex BDM Motorola MPC5xxx Slave | This software package allows the user to work on BDM protocols from the Motorola MPC5xx family of microprocessors. It is recommended tha this SW package be used with FLEX and the complete FLEXible Bench kit to obtain more efficient results and safer working conditions with no connection errors. |
| FLS0.4S | SW Flex Boot Nexus MPC5xxx Slave | This software package allows the user to work on all supported protocols from the Nexus MPC5xxx family of processors for ECUs and TCUs in bootloader mode. |
| FLS0.5S | SW Flex Full Slave | This software package allows the SLAVE user to work on the entire list of over 25,000 vehicles supported by Flex. Main features: – all supported solutions for ECUs and TCUs – coverage of all the available programming modes |
| FLS0.6S | SW Flex OBD/Bench/Boot Renesas SH7xxxx Slave | This software package contains all the protocols for work in OBD, Boot and Bench on ECUs and TCUs that mount Renesas SH7xxxx microprocessors. This SW package also includes protocols for work on Kubota tractors via OBD, Boot and Bench and is is recommended to use these protocols with the FLX2.13 connection cable. |
| FLS0.7S | SW Flex Boot Infineon C165/166/167 Slave | This FLEX SW package allows work in Bootloader mode on all control units that mount C165/166/167 Siemens microprocessors. This family of microprocessors is generally supported by older generation ECUs like ME7 and EDC15. |
| FLS0.8S | SW Flex Boot ST10 Slave | This FLEX SW package allows work in Bootloader on control units that mount ST10F2xx microprocessors. This family of microprocessors is generally supported by Marelli in older generation models, such as IAW and is often equipped with an internal Flash. |
| FLS0.9S | SW Flex JTAG NEC76F00xx Slave | This software package includes protocols for work in JTAG AUD on engine control units that mount NEC76F00xx microprocessors. This family of microprocessors can be found in Toyota Denso 275xxx or 175xxx engine control units. This SW package makes it possible to communicate with the supported units through the JTAG port so in this case, it is necessary to open the control unit. |
| FLS0.10S | WFlex Bench/Boot InfineonTC17xx/TC2xx/TC3xx Slave | Complete Bench MEDC17 software package for programming BOSCH MEDC17 ECUs directly from the engine control unit connector. The best ally for each professional tuner, to always have every single parameter of the vehicle under control during modifying operations. |
| FLS0.11S | Datalogger Plus Slave | The best ally for each professional tuner, to always have every single parameter of the vehicle under control during modifying operations. |
| FLS0.13S | SW Flex Bikes OBD/Bench/Boot Slave | FLEX SW package dedicated entirely to control units for motorcycles |
| FLS0.15S | SW Flex Heavy Duties OBD/Bench/Boot – Slave | FLEX SW package designed to work on all categories of heavy-duty vehicles. |
Who is VIEZU
VIEZU is the biggest seller of tuning systems in the UK! Therefore, the service is open to trade and retail customers alike, as well as offering unbeatable prices. All Magic Motorsport Flex protocols, tools, accessories, and software are kept in stock. In addition, all tool sales include installation, set up, and training. Training is available in-house at our dedicated training facilities, and online too.
Training and support are available 7 days a week. International and tax-free sales are available, with worldwide door-to-door delivery.
